Upgrade Guide

1.0.0 -> 1.1.0

🕓 10-15 mins

This is a significant update that restructures how autopilot features are delivered. Flight-related modules have been extracted into a new companion script called Mother Autopilot System (MAPS). If you use flight plans, docking, or gyro commands, you'll need to install MAPS alongside Mother OS.

Breaking Changes

1. Autopilot Modules Moved to MAPS

The following modules have been removed from Mother OS and are now part of MAPS:

  • FlightControlModule
  • FlightPlanningModule
  • DockingModule
  • GyroModule (now called AttitudeModule)

Action Required

If you use any flight-related commands (nav/set-flight-plan, dock, gyro/face, fcs/*), you must install MAPS into a second programmable block on your grid.

Installation:

  1. Subscribe to MAPS on the Steam Workshop
  2. Load the MAPS script into a new programmable block on your grid
  3. Both scripts will automatically sync during boot

2. Flight Plan Command Renamed

The nav/set-flight-plan command has been renamed to fp/set.

Before:

Terminal
nav/set-flight-plan "GPS:Waypoint1:0:0:0:#FFFFFF:"

After:

Terminal
fp/set "GPS:Waypoint1:0:0:0:#FFFFFF:"

Update any custom commands or hooks that reference nav/set-flight-plan.

3. Display Surface Configuration Changed

Display routing is no longer inferred from block names like MMAP, MALMANAC, or MLOG:1. Instead, assign views directly in the target block's Custom Data using the [surfaces] section.

Before (block name):

LCD Panel [MMAP]

After (Custom Data): Use the [surfaces] section on the display block to assign views to each surface:

Custom Data
[surfaces]
; show the MAPS map view of surface 0
0=MapView

; view a script's log on surface 1
1=LogView "Mother OS"

The block can now be named anything you like. This applies to map, almanac, log, and GUI views.

Tips

Map and Almanac displays are now rendered by MAPS, not Mother Core. Make sure MAPS is installed if you want to use these display types.

4. Debug/Log Display Consolidation

The debug display type has been merged with log. Use log for all logging output.

Migration Checklist

  • [ ] Install MAPS if you use flight/docking features
  • [ ] Replace nav/set-flight-plan with fp/set in all custom commands
  • [ ] Replace gyro/face usage (now in MAPS)
  • [ ] Replace block-name display tags like MMAP, MALMANAC, and MLOG:1 with [surfaces] view assignments
  • [ ] Change any debug display types to log
  • [ ] Run boot command after updating Custom Data

New Features Available

After upgrading, you'll have access to:

  • Variables - Use $VARNAME in commands
  • Command parameters - Define {{param:default}} in custom commands
  • Parallel execution - Run commands simultaneously with {command1} {command2}
  • Wheel commands - wheel/height, wheel/power, wheel/strength, wheel/friction
  • --share flag - Distribute values across block groups
  • Merge block support - onMerge/onUnmerge hooks
  • Mechanical attach/detach - piston/*, rotor/*, and hinge/* now support attach/detach commands and onAttach/onDetach hooks
  • Grid and block renaming - Use rename and block/rename to rename grids and terminal blocks
  • Hexadecimal colors - Use values like #FF0000 anywhere colors are accepted
  • Important commands - Prefix a custom command with ! to make it authoritative across the construct
  • block/rename - Rename blocks programmatically
  • onBoot hook - Trigger commands after boot completes

Other Changes To Expect

  • Automatic command sharing - Mother OS, MAPS, and Mother GUI now share command libraries automatically on the same construct
  • No forced reboot on Custom Data edits - Most programmable block configuration changes refresh without a full reboot
  • Better construct awareness - Merge and mechanical connection changes now refresh block discovery automatically

0.2.14 -> 1.0.0

🕓 5 mins

This is a major release that introduces several new features and improvements. I highly recommend updating Mother OS on all of your grids to ensure compatibility and take advantage of the latest features. It never hurts to run the purge * --force command to clear out old data.

This version introduces automatic refreshing to block custom data meaning you should only need to reach for the boot command, or hit recompile when things go wrong. This has massively improved our productivity and I'm sure it will for you too. You now also print messages to cockpit screens, and change both text and background colors.

Enjoy!

0.2.13 -> 0.2.14

🕓 5 mins

This update introduces changes to the way your grids communicate. I highly advise installing the latest version on Mother on all of your grids. Mother Core now uses a Version Manager to help with this.

If you are encountering issues or the rare complexity failure, you should purge storage to clear all data related to grid communications.

Terminal
purge * --force

0.2.12 -> 0.2.13

🕓 0 mins

This update makes major changes to the boot process but does not require any changes to your existing scripts.

Players can now use the boot command to run the Mother OS boot sequence. This is automatically run when the Programmable Block is started, but can be run manually to reset the system.

Players can also increment and decrement inputs for various commands like hinge/rotate and piston/distance using the add and sub command options.

0.2.11 -> 0.2.12

🕓 5 mins

This update ensures compatibility with the new Fieldwork Update (1.206). This should fix Mother across your grids caused by changes to the programmable block API by Keen. Thanks for your patience with this one!

Important

You will need to refresh Mother in all of your grids.

  • Players will also have access to the following hooks:

    • Air Vent

      • onPressurizing - Activated when an air vent is in the Pressurizing state.
      • onDepressurizing - Activated when an air vent is in the Depressurizing state.
      • onPressurized - Activated when an air vent is in the Pressurized state.
      • onDepressurized - Activated when an air vent is in the Depressurized state.

    • Piston

      • onExtended - Activated when a piston is in the Extended state.
      • onRetracted - Activated when a piston is in the Retracted state.
      • onExtending - Activated when a piston is in the Extending state.
      • onRetracting - Activated when a piston is in the Retracting state.

    • Door

      • onClosing - Activated when a door is in the Closing state.
      • onOpening - Activated when a door is in the Opening state.

Players may now use the block/toggle command to toggle a block's on/off state.

0.2.10 -> 0.2.11

🕓 0 mins

  • Players can now use the following new commands:

    • dampeners/on - Turns on the dampeners of the ship (aircraft).
    • dampeners/off - Turns off the dampeners of the ship (aircraft).
    • handbrake/on - Turns on the handbrake of the ship (rover).
    • handbrake/off - Turns off the handbrake of the ship (rover).

  • Players can now print multi-line messages to LCD panels.

v0.2.11 Video

0.2.9 -> 0.2.10

🕓 0 mins

  • Players can now target blocks with #tags. Tags provide a flexible alternative to using terminal groups to associate your blocks by function and targeting them with commands.

v0.2.10 Video

0.2.8 -> 0.2.9

🕓 0 mins

Features

  • screen/print command allows players to print custom messagesm to LCD panels.
  • Autodocking has been improved and contains several failsafes to protect player grids. Planetary docking should be attempted with caution but zero-g docking is very reliable.

0.2.7 -> 0.2.8

🕓 0 mins

Features

  • Autodocking with the dock command.
  • Improved performance and hook capabilities. Doors now trigger hooks when the player interacts with them.
  • New documentation suite to assist with building automations with Mother.

0.2.8 Video

Migration

You do not need to change anything to upgrade to this version. Woohoo!

0.2.7

0.2.7 Video

Last Updated:
Contributors: Luke Morrison, lukejamesmorrison
